Platform & Reach Work height: 44′ 11″ Raised platform height: 38′ 11″ Lowered platform height: 56″ Dimensions Overall width: 47″ Overall length (platform retracted): 94.5″ Stowed height (rails up/down): 99.5″ / 79.5″ Platform inside width × length: 42″ × 86″ Extension deck (roll-out): 3′ Wheelbase: 73″ Ground clearance (pothole system): 4.5″ (raised) / 0.5″ (deployed) Performance Machine weight: 6,467 lb Gradeability: 25% Turning radius: inside 17.5″, outside 99″ Drive speed (stowed/raised): 1.9 mph / 0.5 mph Lift/lower cycle time (rated load): Lift 68 sec, Lower 41 sec Capacity Overall platform capacity: 770 lb Main platform: 505 lb Extension deck: 265 lb Max occupants: 3 people (up to 0 mph wind); 1 person up to 28 mph wind rating Local floor load: 139 psi Overall floor load: 233 psf Tires & Power Tires: 16″ × 5″ × 12″ solid, non-marking Electrical system: 24 V DC, AGM batteries, low-voltage protection Includes 110 V AC outlet with GFI on platform Standard Features Drivable at full height, variable-speed front-wheel hydraulic drive Dual holding brakes, tilt sensor with auto cut-out, tilt/driving/lift alarm systems On-board diagnostics, proportional joystick controls SKYCODED wiring, impact-resistant control box Pothole protection and overload sensing Fold-down hinged railings, half-height spring gate, lanyard attachment Forklift pockets, tie-down/lift lugs, operator horn 110 V AC outlet, flashing lights, tool caddy, board carrier AGMs, smart charger, telematics-ready (ELEVATE system)
